Small Bathroom Layouts That Work in Tight Spaces

Mews houses are some of the most charming homes in Britain, but nobody ever designed a stable block with a spa bathroom in mind. The typical mews property gives you a narrow footprint, a low eaves line and perhaps a single window, so the bathroom often ends up squeezed into whatever space is left over. The good news is that a tight bathroom does not have to feel like a compromise. With the right layout choices, a space of 2 metres by 1.7 metres can work comfortably for a family of four.

Start With the Shape, Not the Style

Before you fall in love with a particular tile or vanity, measure the room properly and draw it out on graph paper. Note the position of the soil stack, the window, the door swing and any boxing in around pipes or chimneys. In mews conversions, the soil stack is usually the fixed point that dictates where the toilet can go, and moving it is expensive and sometimes impossible without consent.

Mark out the clear floor space you actually need:

In front of the toilet: around 600mm of clear space for comfortable use.
In front of the basin: roughly 700mm if you want to dry yourself without bumping elbows.
Toilet width: allow 750–800mm between walls for a WC, with the pan itself usually 350–400mm wide.
Walk-in shower: 900 x 900mm is generous, 800 x 800mm is workable, and anything below 760mm starts to feel mean.

Once you know what must fit, the layout usually solves itself. The trick is resisting the urge to put a bath in a room that simply cannot take one.

Corner Basins and Wall Hung Toilets

A corner basin is the single easiest win in a narrow bathroom. A 450mm corner model tucks neatly into an awkward junction and leaves the centre of the room clear, which is exactly where you need elbow room. Where the walls allow, a shallow 500mm-deep semi-recessed basin set into a slim worktop can give you storage underneath without stealing floor space.

Wall hung toilets are worth the extra cost in a mews property for two reasons. First, the pan projects less far into the room than a close-coupled model, typically 480–530mm from the wall rather than 650mm or more. Second, the concealed cistern sits inside a framed duct that runs up to the ceiling, giving you a shelf or a shallow cupboard above. Choose a wall hung frame with a slim 80mm duct if space is very tight, and make sure the frame is fixed to a solid wall or properly braced timber stud — the pan carries real weight.

If you cannot move the soil stack, a raised or repositioned pan may need a macerator. They work, but they are noisy and need careful use. Treat them as a last resort rather than a first choice.

Walk-In Showers Instead of a Bath

Ask yourself honestly how often the bath is used. In most mews en-suites, a generous walk-in shower serves far better. A 900 x 900mm shower tray with a single fixed glass panel and no door gives you a genuinely comfortable space and removes the swing of a screen or a shower curtain from the equation.

For a wet room look, tank the floor properly and use a linear drain along the wall rather than a centre waste, which makes the floor easier to slope and avoids a puddle trap underfoot. A 10–12mm frameless glass panel fixed to the wall keeps the room feeling open, and a low-profile tray of 25–40mm means no step to trip over.

Where you must keep a bath — for children, or for resale — look at a 1500mm or 1600mm short bath combined with a shower over it. It is not luxurious, but it is honest about the space available. Position the bath along the longest wall and run the shower off the same wall to avoid a second wet zone.

Working With Alcoves, Sloping Ceilings and Low Eaves

Mews bathrooms are rarely rectangular, and those odd shapes are an opportunity. A chimney breast gives you two natural recesses either side — ideal for a basin on one side and a tall slim cupboard on the other. Under the eaves, a low run of 900mm-high units can hold towels and toiletries without eating into head height where you stand.

Order of priority when space is scarce:

Toilet and basin first, positioned so neither is blocked by the door.
Shower second, ideally in the furthest corner from the door.
Storage third, squeezed into alcoves and above the door if the ceiling allows.
Heated towel rail last, but never skip it — a warm bathroom dries faster and feels twice the size.

Light, Ventilation and the Details That Buy Space

Light colours on walls and a large format tile with minimal grout lines will always make a small room read bigger, but the real gains come from light itself. If you have a window, resist covering it with a bulky blind. A mirrored cabinet above the basin bounces light around and stores everything you would otherwise stack on the sill.

Ventilation matters more than most people expect. A ceiling-mounted extractor rated at 15 litres per second, or an inline fan ducted to the outside, will keep a windowless mews bathroom free of mould. Leave the door undercut by 10mm so air can move.

Finally, think about sound. Mews bathrooms often sit next to bedrooms, so consider a quiet cistern, solid-core doors and acoustic insulation in the stud walls if you are renovating anyway. It is a small detail that makes a tight bathroom feel far more civilised.
